Description
Specifications:
| Voltage: | 24/36/48V |
| Power: | 350-500W |
| Motor Type: | Brushless Geared Hub Motor |
| Motor Net Weight: | 3.8kgs |
| Reduction ratio: | 1:4.4 |
| Open size: | 100mm/135mm (F/R) |
| Brake type: | V/ Disc brake |
| Motor cable length: | 160cm |
| Hall Sensor: | Option |
| Max. Speed: | 25±1 |
| Max. Torque: | 15N.M |
| Noise | < 50 |
| Waterproof grade | IP54 |
| Salt spray test (H) | 24/96 |
Design Options:
- Operating voltages to suit
- Custom shaft(Axis)sizes/profiles
- Tailored performance profiles
- Special OEM configurations
